Low‑Power Relay
CHFN-H
Withstand voltage strength between coil and contacts: 4,500 VAC
Contact gap: >2.0 mm
Overall dimensions: (30.1 × 15.7 × 26.5) mm
Certification：
Application：
Solar inverters, energy storage PCS, AC/DC power control
Main Parameters
Coil Voltage Type: | DC | Coil Operating Voltage (V): | 12、24 | Contact Form: | 1NO | Contact Number: | Single Contact | Terminal Type： | PCB Mount |
Mounting Type: | — | Package Type: | Solder-flux resistant type & sealed housing | Terminal Configuration： | PCB Mount | Coil Power： | 1.4W | Coil Characteristic: | Monostable |
Contact Material: | Silver Alloy | Insulation Class: | F | Coil Parallel Component: | - | Packing Type： | Blister pack | Rated Load Voltage： | 250VAC |
Rated Load Current: | 31A、35A | Dielectric Withstand Voltage (Between Coil and Contacts): | 4500VAC 1min | Operate Time (ms): | ≤20 | Release Time (ms): | ≤10 | Operating Ambient Temperature | -40℃~85℃ |
| Mechanical Life (cycles)： | 5000000 | Electrical Life (cycles)： | 30000(Please refer to datasheet for more details.) | Weight (g): | ≈23 | Volume (mm³): | 30.1×15.7×26.5 | Applications： | Solar Inverters, Energy Storage PCS, AC/DC Power Control and other fields. |
