| Item | Description | Rating | Item | Description | Rating |
| 1 | 供电电压 Operation Supply Voltage (Vcc) | 4.75~5.25 VDC | 8 | 耐受压力 Proof Pressure | 750 BarG |
| 2 | 消耗电流 Current Consumption | 10mA Max | 9 | 爆破压力 Burst Pressure | 1000 BarG |
| 3 | 上拉电阻 | 4.4~4.87 kohm | 10 | 响应时间 Response Time | 2ms Max |
| 4 | 工作温度 Operation Temperature | -40~140 ℃ | 11 | 安装扭矩（仅使用套筒扳手）Mounting Torque (Socket Wrench Only) | 30~35 Nm，40 Nm.Max |
| 5 | 存储温度 Storage Temperature | -40~85 ℃ | 12 | 反向电压 Reverse Voltage | -28 V |
| 6 | 输出信号 Output Type | Analog | 13 | 过电压 Overvoltage | 40 V |
| 7 | 满量程压力 Full Scale Pressure | 470 BarG | 14 | IP 防护等级 IP Protection Rating | IP67 |
